High security fence galvanized 358 fence welded wire mesh panel fencing
Description:
High Security Fence galvanized 358 Fence welded wire mesh panel fencing
1.Material: Low carbon steel wire, PVC caoted wire
2.Wire Diameter: 2.0mm-5.0mm
3.Mesh:12.7mm x 76.2mm
4.Width: 2m 2.5m 3m
5.Height: 1.8m 2.0m 2.3m
6.Surface Treatment: galvanized + powder coated
Specification:
358 Wire Fence is composed with quadrate post and high strength welded wire fence;
358 Wire Fence has a strong erosion resistance and anti-ultraviolet;
358 Wire Fence connected by screw flat bar, the installation is very easy and convenient.
| Wire Diameter | Mesh Size | Width | Height | Post Height | Post Type | Fitting |
3.0mm
3.5mm
4.0mm |
1/2"*3"
(12.7*76.2mm) |
2000mm
2200mm
2500mm | 1000mm
1200mm
1500mm
1800mm
2000mm
2200mm
2400mm
3000mm | 1400mm
1600mm
2000mm
2300mm
2500mm
2800mm
3000mm
3800mm |
Model
No.DQA-04 |
Flat Plate |
Features:
Using high quality iron rod as raw material, the welded panel, after galvanization, powders primer, and powders top coating, it can resist the corrosive and ultraviolet radiation very strongly.
| Surface Treatment | Min. | Max. |
| Electric Gal. | 20/m2 | 60/m2 |
| Hot dipped Gal. | 35g/m2 | 700g/m2 |
| Powders Sprayed coating | 100 microns | 120 microns |
The design of anti-cutting has a strong body, can reduce the destroy and anti-climbing.
3.Choice of colors:
Every RAL colour desired can be delivered, for example the colours corresponding to your corporate design.
- Common colors
- Dark Green RAL6005
- Pure White RAL9010
- Stone Grey RAL7030
- Jet Black RAL9005
- Anthracite Grey RAL7016
- Other RAL colors are available
Application:
Power station, commonality construction, jail, airport, military base, country border and other high security area and place.
Extra choose the angle steel, barbed wire or razor wire fence to make more security.
